Chlorine Dioxide (ClO2) Gas Detectors

Chlorine dioxide (ClO2) is an anthropogenic gas, meaning it cannot be found naturally. Chlorine dioxide is most commonly used in sanitizing drinking water and bleaching pulp, flour, and textiles. The gas is highly flammable and reactive—it poses both a fire and explosion hazard.

pulp-paper (1)
Sections

Characteristics of Chlorine Dioxide

Chlorine Dioxide is a red-yellow or orange-green gas with an unpleasant irritating odor, similar to chlorine and nitric acid. It is best known for its biocide and disinfectant properties.

Chlorine dioxide can remain rather stable in the dark, but can become very unstable in the light. Chlorine Dioxide will react or form an explosive compound if exposed to a spark, impact, sunlight or rapid heating of up to 100°C. Chlorine Dioxide may also react with carbon monoxide, hydrocarbons, mercury, and some nonmetals as well. ClO2 combined with water will form hydrochloric acid, and it has a very strong irritating effect on the upper respiratory tract.

More about Chlorine Dioxide expand table collapse table

CHLORINE DIOXIDE - ClO2

Hazard:
Flammable
Will not explode
Classification:
Health
Extremely toxic
Classification:
Oxidizing
Oxidizing agent
Synonyms:
Anthium Dioxide, Chlorine Oxide, Chlorine Peroxide
Exposure limits:
(OSHA)
PEL\TWA: 0.1 ppm
(ACGIH)
STEL: 3 ppm
(OSHA)
IDLH: 5 ppm
Industries:
Pulp and paper mills, wastewater treatment plants

Effects of Various ClO2 Levels

ClO2 Level in PPM
Resulting Conditions on Humans
.1
Odor threshold and Permissible Exposure Limit (PEL).
.25
Mild respiratory ailments.
.3
Short Term Exposure Level (STEL).
5
Marked irritation occurs of the respiratory tract. Immediately Dangerous to Life and Health (IDLH).
>5
Irritation of the eyes, nose and throat; cough; wheezing; shortness of breath; bronchitis; pulmonary edema; headache; vomiting.

How to Detect Chlorine Dioxide

Industrial Scientific offers the GasBadge® Pro personal single-gas detector and the MX6 iBrid® personal multi-gas detector to keep workers safe in areas where chlorine dioxide gas may be present. This includes confined spaces where explosive concentrations of the gas may accumulate.

Multi-Gas Monitor

MX6 iBrid

learn more arrow icon
SINGLE-GAS MONITOR

GasBadge Pro

learn more arrow icon
MULTI-GAS MONITOR

Radius BZ1

learn more arrow icon
